STOP&GO 8 PLUS-MINUS High-voltage device with ultrasound

STOP&GO 8 PLUS-MINUS High-voltage device with ultrasound

The original – double stainless steel contact plates – no need to connect to on-board power supply – ultrathin design

2 x 3 volt button batteries (CR2477) make the 8 PLUS-MINUS completely independent of the on-board power supply for up to 18 months per battery set. The connection to terminal 15 has been replaced by innovative sensor technology, and a slide contact attached directly to the device eliminates the need to install a bonnet contact switch. Ideal for vehicles that remain parked for long periods such as motor homes, classic cars, etc. Especially suited for battery management systems (BMS) and alternative drives such as electric, hybrid, gas, etc.

We also highly recommend using the STOP&GO marten odour remover prior to taking any other marten protection measures.

Additional features:

• Battery operated
• Sensor technology
• Power consumption: approx. 0.2 mA
• Batteries last up to 18 months
• 6 stainless steel contact plates with a plus and minus pole
• 2 waterproof piezo speakers
• Dispersion radius: 360°
• Dispersion angle: > 170°
• Sound pressure: approx. 110 dB
• Frequency modulation to prevent habituation
• Function control light, blinking LED
• Waterproof in accordance with IP65
• Panic protection control
• Also suitable for home and carport
• E1 marking by the German Federal Motor Transport Authority (KBA)

Technical data:

• Operating voltage: 2 x 3 V (button batteries CR 2477)
• Power consumption: approx. 0.2 mA (including after a short circuit)
• Battery life: up to 18 months
• High voltage: yes
• Output voltage: ca. 300 V
• Ultrasound: yes
• Ultrasound frequency: 20–25 KHz, frequency modulation
• Dispersion radius: 360°
• Dispersion angle: > 170°
• Sound pressure: approx. 110 dB
• Function control light: red LED
• Moisture protection: waterproof in accordance with IP65
